Drip Pipe - Pressure Compensating Pipe

Pressure-compensating drip irrigation pipe is a drip irrigation belt with built-in pressure-compensating drippers. Its unique design makes it perform well in rugged terrain such as hills and mountains. This drip irrigation pipe can effectively solve the problem of uneven pressure caused by terrain drop, ensure that each dripper can evenly discharge water, and provide a stable water supply for crops. Whether it is planting fruit trees, vegetables or other crops, pressure-compensating drip irrigation pipes can play an important role, improve irrigation efficiency, save water resources, and are an ideal choice for agricultural irrigation.

Diameter：16mm

Material：PE

Color：Any colors can be done

Series：Irrigation

Prev: PE Tape -Micro spray tape

Next: Drip Pipe - with cylindrical emitter inside

Detail

Product Features

The pressure-compensating drip irrigation pipe is extruded once, with built-in pressure-compensating drippers. There is no need to
install drippers manually, and the laying construction is convenient and labor-saving

The pressure-compensating dripper has a labyrinth flow channel, a scientific structure, stable silicone sheet quality, and good pressure
compensation effect
The inner dripper has a small manufacturing deviation, uniform water flow, and has an anti-backflow function to prevent debris from being
sucked into the flow channel. It can be used for underground irrigation
The pressure-compensating drip irrigation pipe is made of high-quality materials, corrosion-resistant, anti-aging, and durable

Specifications

Diameter(mm)	Thickness( mm )	Spacing(cm)	Flow rate(L/H)	Working pressure (Bar)	Package/roll (m)
16	0.4mm	20/30/40/50	1.0/1.6/2.0	1.0-1.8	700/800
16	0.6mm	30/40/50/100	1.0/1.6/2.0	1.0-2.0	500
16	0.8mm	30/40/50	1.0/1.6/2.0	1.0-2.2	500
16	1.0mm	30/40/50	1.0/1.6/2.0	1.0-2.5	500
Note: Customizable
